3-182 Phaser 5500 Printer Service Manual
Punch Failure (Side Registration Sensors) Troubleshooting Procedure
Step Actions and Questions Yes No
1
Check the Punch operation.
Move the Punch Unit in and out.
Does the punch move smoothly?
Go to Step 2. Correct the
installation.
2
Test the Punch Move Motor.
Run the Service Diagnostics Front and
Rear Punch Move Motor tests.
Does the Punch Move Motor rotate and
the Punch frame move?
Go to Step 8. Go to Step 3.
3
Check Punch Move Motor Harness
connections.
Are P/J8344 and P/J8306 connected?
Go to Step 5. Connect and go
to Step 4.
4
Print a Test Print.
Does the error still occur?
Go to Step 5. Problem solved.
5
Check Punch Move Motor Harness
continuity.
1. Disconnect P/J8344 and P/J8306.
2. Check for continuity at the following:
P/J8344-1 <=> P/J8306-7
P/J8344-2 <=> P/J8306-3
P/J8344-3 <=> P/J8306-6
P/J8344-4 <=> P/J8306-5
P/J8344-5 <=> P/J8306-2
P/J8344-6 <=> P/J8306-1
Are these conductive?
Go to Step 6. Repair the Punch
Move Motor
Harness.
6
Replace the Bracket Assy-Motor, Punch.
Print a Test Print.
Does the error still occur?
Go to Step 7. Problem solved.
7
Replace the Finisher Main PWB.
Does the error still occur?
Replace the
Finisher Main
PWB
(
page 3-248).
Problem solved.
8
Test the Side Regi Sensor 1.
Run the Service Diagnostics Side
Registration Sensor 1 test.
Does the state change when the sensor
is blocked?
Replace the
Finisher Main
PWB
(
page 3-248).
Go to Step 9.
9
Test the Side Regi Sensor 2.
Run the Service Diagnostics Side
Registration Sensor 2 test.
Does the state change when the senor
is blocked?
Replace the
Finisher Main
PWB
(
page 3-248).
Go to Step 10.
