Fuji Xerox Phaser 5500 User Manual

Error Messages, Codes, and Procedures 3-183
10
Check the harness connections.
Are P/J8307, P/J8333 and P/J8350 (for
Side Regi Sensor 1), and P/J8351 (for
Side Regi Sensor 2) connected?
Go to Step 12. Connect and go
to Step 11.
11
Print a Test Print.
Does the error still occur?
Go to Step 12. Problem solved.
12
Check Main Punch Sensor continuity.
Disconnect P/J8307 and P/J8333.
Is there continuity on each wire
between J8307 <=> J8333?
Go to Step 13. Repair the Main
Punch Sensor
Harness.
13
Check Side Regi Sensor continuity.
1. Disconnect P/J8333, P/J8350 (Side
Regi Sensor 1), and P/J8351 (Side Regi
Sensor 2).
2. Check for continuity at the following:
P/J8333-13 <=> P/J8350-3
P8333-14 <=> P/J8350-2
P8333-15 <=> P/J8350-1
P8333-16 <=>P/J8351-3
P8333-17 <=> P/J8351-2
P8333-18 <=> P/J8351-1
Are these conductive?
Go to Step 14. Repair the Punch
Unit Harness.
14
Check for +5 V at Side Regi Sensor 1
Is there +5 V between P/J8307-A10 <=>
P/J8307-A12?
Go to Step 16 Go to Step 18
15
Check for +5 V at Side Regi Sensor 2
Is there +5 V between P/J8307-A7 <=> P/
J8307-A9?
Go to Step 17 Go to Step 18.
16
Replace the Side Registration Sensor 1.
Print a Test Print.
Does the error still occur?
Go to Step 18. Problem solved.
17
Replace the Side Registration Sensor 2.
Print a Test Print.
Does the error still occur?
Go to Step 18. Problem solved.
18
Replace the Finisher Main PWB.
Does the error still occur?
Replace the
Engine Logic
Board
(
page 8-89).
Problem solved.
Punch Failure (Side Registration Sensors) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
