Error Messages, Codes, and Procedures 3-43
8
Check for +5 V at the Fuser Exit Sensor.
Is there +5 V across the sensor
connector’s P/J125-3 <=> ground?
Replace the Fuser
Exit Sensor
(
page 8-77).
Replace the
Engine Logic
Board
(
page 8-89).
9
Test the Exit 1 Motor operation.
Run the Service Diagnostics Exit 1 Motor
tests.
Does the motor operate properly?
Go to Step 18. Go to Step 10.
10
Check the Exit 1 Motor connection.
Are P/J206 and P/J432 connected?
Go to Step 11. Connect P/J206
and P/J432.
11
Check continuity between the Exit 2 Motor
and Engine Logic Board.
Is there continuity on each wire
between P/J206 <=> P/J432?
Go to Step 12. Repair the wiring.
12
Check for +24 V to the Exit 1 Motor.
Is there +24 V across P206-5 (+) <=>
ground?
Replace the Exit 1
Offset Motor
(
page 8-80).
Go to Step 13.
13
Check the connection between the Exit
PWB and Engine Logic Board,
Are P/J431 and P/J421 connected?
Go to Step 14. Connect P/J431
and P/J421.
14
Check continuity between the Exit PWB
and the Engine Logic Board.
Is there continuity on each wire
between P/J431 <=> P/J421?
Go to Step 15. Repair the wiring.
15
Check the connection between the Exit
PWB and the LVPS.
Are P/J430 and P/J526 connected?
Go to Step 16. Connect P/J430
and P/J526.
16
Check continuity between the Exit PWB
and the LVPS.
Is there continuity on each wire
between P/J430 <=> P/J526?
Go to Step 17. Repair the wiring.
17
Check for +24 V to the Exit PWB.
Is there +24 V across P/J430-1 (+) <=>
ground?
Replace the Exit
PWB (
page 8-88).
Replace the
LVPS
(
page 8-92).
18
Test the Exit 2 Exit Sensor.
1. Open Door E.
2. Run the Service Diagnostics Exit Sensor
test.
Does the sensor change state?
Replace the
Engine Logic
Board
(
page 8-89).
Go to Step 19.
19
Check the Exit 2 Exit Sensor connection.
Are P/J112, P/J606B, and P/J434
connected?
Go to Step 20. Connect the
sensor.
E4-1 Exit 2 Area Jam Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
To Next Page
