Error Messages, Codes, and Procedures 3-69
6
Check the Feeder Harness for continuity
1. Disconnect PF61 and PF56B.
2. Check for continuity of the following:
PF61-1 <=> JF56B-3
PF61-2 <=> JF56B-2
PF61-3 <=> JF56B-1
Are these three conductive?
Go to Step 7. Repair the Feeder
Harness.
7
Check the Main Harness for continuity
1. Disconnect PF56B and JF02.
2. Check for continuity at the following:
JF56B-4 <=> JF02-6
JF56B-5 <=> JF02-5
JF56B-6 <=> JF02-4
Are these three conductive?
Go to Step 8. Repair the Main
Harness.
8
Check for +5 V at the Pre-Feed Sensor.
Is the voltage across PF02-6 <=> PF04-2
on the PWB +5 V?
Go to Step 9. Replace the Tray
6 PWB
(
page 3-67).
9
Check the Pre-Feed Sensor function.
Does the voltage across JF02-5 <=>
PF04-2 on the PWB change, when white
paper is placed over the sensing area?
Go to Step 27. Replace the Pre-
Feed Sensor
(
page 3-51).
10
Test the Feed/Lift Motor.
Run the Service Diagnostics Tray 6
Motor Feed test.
Does the Feed/Lift Motor rotate
normally?
Go to Step 18. Go to Step 11.
11
Check the Harness connections.
Are the connectors PF58, PF56, and
JF06 on the PWB connected?
Go to Step 13. Connect and go
to Step 12.
12
Print a Test Print.
Does the error still occur?
Go to Step 13. Problem solved.
13
Check the Feeder Harness for continuity
1. Disconnect PF58 and JF56B.
2. Check for continuity at the following:
PF58-1 <=> JF56-1
PF58-2 <=> JF56-2
PF58-3 <=> JF56-3
PF58-4 <=> JF56-4
PF58-5 <=> JF56-5
PF58-6 <=> JF56-6
Are these conductive?
Go to Step 14. Repair the Feeder
harness.
Jam at Tray 6 (Feed Out Sensor #6) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
To Next Page
