Error Messages, Codes, and Procedures 3-99
Static Jam at F (Transport Entrance Sensor) Troubleshooting Reference
Applicable Parts References
■ X’port Entrance Sensor
■ Harness Main SNR
■ Harness Ent. Sensor
■ Harness Main Drive
■ Finisher Main PWB
■ Transport Motor
■ Phaser 5500 Printer Options Service Manual
■ Finisher Main PWB P/J Locator (page 5-35)
■ Finisher Sensors (1/2) Wiring (page 5-40)
■ Finisher Motors Wiring (page 5-42)
■ PL25.12 Finisher Transport (1/2) (page 4-66)
■ PL25.14 Finisher Electrical (page 4-70)
■ PL25.15 Finisher Harness (page 4-72)
Static Jam at F (Transport Entrance Sensor) Troubleshooting Procedure
Step Actions and Questions Yes No
1
Test the H-’Xport Entrance Sensor.
1. Open Door F.
2. Run the Service Diagnostic H-’Xport
Entrance Sensor test.
Does the sensor change state?
Go to Step 8. Go to Step 2.
2
Check the Sensor Harness connections.
Is the harness connected to the sensor
and Finisher correctly?
Go to Step 4. Connect and go
to Step 3.
3
Print a Test Print.
Does the error still occur?
Go to Step 4. Problem solved.
4
Check Sensor Harness continuity.
1. Disconnect P/J8319 and P/J8303B.
2. Check for continuity at the following:
J8319-3 <=> J8303B-1
J8319-2 <=> J8303B-2
J8319-1 <=> J8303B-3
Are these conductive?
Go to Step 5. Repair the
Sensor Harness.
5
Check Main Sensor Harness continuity.
1. Disconnect P/J8303A on the harness,
and P/J8302A on the Finisher Main
PWB.
2. Check for continuity at the following:
J8303A-3 <=> J8302A-1
J8303A-2 <=> J8302A-2
J8303A-1 <=> J8302A-3
Are these conductive?
Go to Step 6. Repair the Main
Sensor Harness.
6
Check for +5 V to the Entrance Sensor.
Is there +5 V across J8302A-3 <=>
J8302A-1 on the Finisher Main PWB?
Go to Step 7. Replace the
Finisher Main
PWB
(
page 3-248).
