3-128 Phaser 5500 Printer Service Manual
10
Test the Upper Tray Exit Sensor.
Run the Service Diagnostics Upper Tray
Exit Sensor test.
Does the sensor state change?
Replace the
Finisher Main
PWB
(
page 3-248).
Go to Step 11.
11
Check the Upper Tray Exit Sensor Harness
connections.
Are P/J8321 and P/J8312 on the sensor
harness, and P/J8312 and P/J8302 on
the Main Sensor Harness connected?
Go to Step 13. Connect and go
to Step 12.
12
Print a Test Print.
Does the error still occur?
Go to Step 13. Problem solved.
13
Check Exit Sensor Harness continuity.
1. Disconnect P/J8321 and P/J8312.
2. Check for continuity at the following:
P/J8321-3 <=> J8312B-1
P/J8321-2 <=> J8312B-2
P/J8321-1 <=> J8312B-3
Are these conductive?
Go to Step 14. Repair the Upper
Tray Exit Sensor
Harness.
14
Check Main Exit Sensor Harness
continuity.
1. Disconnect P/J8312 from the harness,
and P/J8302A on the Finisher Main
PWB.
2. Check for continuity at the following:
J8312A-3 <=> P/J8302A-7
J8312A-2 <=> P/J8302A-8
J8312A-1 <=> P/J8302A-9
Are these conductive?
Go to Step 15. Repair the Main
Sensor Harness.
15
Check for +5 V to the Upper Tray Exit
Sensor.
Is there +5 V across J8302A-9 <=>
J8302A-7 on the Finisher Main PWB?
Go to Step 16. Replace the
Finisher Main
PWB
(
page 3-248).
16
Check the Upper Tray Exit Sensor signal.
Does the voltage across P8302A-8 <=>
P8302A-7 on the Finisher Main PWB
change when the sensor is actuated?
Replace the
Finisher Main
PWB
(
page 3-248).
Replace the
Upper Tray Exit
Sensor
(
page 3-226).
Jam at F or Upper Tray (Exit Sensor OFF) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
To Next Page
