Error Messages, Codes, and Procedures 3-147
25
Test for +24.5 V to the Nudger Solenoid.
Run the Service Diagnostics Nudger
Solenoid High Power test.
Is there +24.5 V across PF06-13 <=> P/
JF04-2 on the Tray 6 PWB?
Go to Step 26. Replace the Tray
6 PWB
(
page 3-67).
26
Test for +14.7 V Nudger Solenoid.
Run the Service Diagnostics Nudger
Solenoid Low Power test.
Is there +14.7V across PF06-13 <=> P/
JF04-2 on the Tray 6 PWB?
Go to Step 27. Replace the Tray
6 PWB
(
page 3-67).
27
Replace the Nudger Solenoid.
Does the error still occur?
Go to Step 36. Problem solved.
28
Test the Feed/Lift Motor.
Run the Service Diagnostics Tray 6 Lift
Motor test.
Does the Tray raise?
Go to Step 36. Go to Step 29.
29
Check the harness connections.
Are PF58 and PF56 on the Feeder and
Main Harness, and JF06 on the Tray 6
PWB connected?
Go to Step 31. Connect and go
to Step 30.
30
Check the repair.
Does the error still occur?
Go to Step 31. Problem solved.
31
Check Feeder Harness continuity.
1. Disconnect PF58 and JF56.
2. Check for continuity at the following:
PF58-1 <=> JF56-1
PF58-2 <=> JF56-2
PF58-3 <=> JF56-3
PF58-4 <=> JF56-4
PF58-5 <=> JF56-5
PF58-6 <=> JF56-6
Are these conductive?
Go to Step 32. Repair the Feeder
Harness.
32
Check Main Harness continuity.
1. Disconnect PF56 and JF06.
2. Check for continuity at the following:
PF56-1 <=> JF06-1
PF56-2 <=> JF06-3
PF56-3 <=> JF06-2
PF56-4 <=> JF06-6
PF56-5 <=> JF06-4
PF56-6 <=> JF06-5
Are these conductive?
Go to Step 33. Repair the Main
Harness.
Tray 6 Failure Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
