Error Messages, Codes, and Procedures 3-167
12
Check for +5 V to Stack Height Sensor 2.
Is there +5 V across J8302A-18 <=>
J8302A-16 on the Finisher Main PWB?
Go to Step 13. Replace the
Finisher Main
PWB
(
page 3-248).
13
Check Stack Height Sensor 2 signal.
Does the voltage across P8302A-17 <=>
P8302A-16 on the Finisher Main PWB
change when the sensor is blocked?
Replace the
Finisher Main
PWB
(
page 3-248).
Replace Stack
Height Sensor 2
(
page 3-141).
14
Test the Stacker Encoder Sensor.
Run the Service Diagnostics Stacker
Encoder Sensor test.
Does the sensor state change when the
Elevator Motor Belt is moved by hand
rotating the Encoder Wheel?
Go to Step 20. Go to Step 15.
15
Check Stacker Encoder Sensor Harness
connections.
Are P/J8328 and P/J8302B connected?
Go to Step 17. Connect and go
to Step 16.
16
Print a Test Print.
Does the error still occur?
Go to Step 17. Problem solved.
17
Check Stacker Encoder Sensor Harness
continuity.
1. Disconnect P/J8328 on the harness, and
P/J8302B on the Finisher Main PWB.
2. Check for continuity at the following:
P/J8328-3 <=> P/J8302B-12
P/J8328-2 <=> P/J8302B-13
P/J8328-1 <=> P/J8302B-14
Are these conductive?
Go to Step 18. Repair the
Stacker Encoder
Sensor Harness.
18
Check for +5 V to Stacker Encoder Sensor.
Is the voltage across J8302B-14 <=>
J8302B-12 on the Finisher Main PWB?
Go to Step 19. Replace the
Finisher Main
PWB
(
page 3-248).
19
Check Stacker Encoder Sensor signal.
Does the voltage across P8302B-13 and
P8302B-12 on the Finisher Main PWB
change when the sensor is blocked?
Replace the
Finisher Main
PWB
(
page 3-248).
Replace Stacker
Encoder Sensor
(
page 3-142).
20
Test the Elevator Motor.
Run the Service Diagnostics Stacker Motor
Up and Down tests alternately.
Does the Elevator Motor operate?
Replace the
Finisher Main
PWB
(
page 3-248).
Go to Step 21.
21
Check the Elevator Motor connection.
Is P/J8305 connected to the Finisher
Main PWB?
Go to Step 22. Connect and go
to Step 22.
Stacker Lower Trail Failure (Stacker Encoder Sensor) Troubleshooting Procedure
Step Actions and Questions Yes No
To Next Page
