Fuji Xerox Phaser 5500 User Manual

Error Messages, Codes, and Procedures 3-205
Replace Incorrect Toner Cartridge - J8-3 Toner Cart.
Type Mismatch
Applicable Error Codes
Replace Incorrect Toner Cartridge - J8-3 Toner Cart. type mismatch
Non-Xerox Toner Cartridge
Non-Xerox Toner Cartridge Troubleshooting Reference
Applicable Parts References
■ Toner Cartridge
■ Toner Cartridge
CRUM PWB
■ Engine Logic Board
■ Print Engine P/J Drum and Toner (page 10-6)
■ Print Engine P/J Engine Logic Board (page 10-13)
■ Print Engine Drive/CRUM Wiring (page 10-25)
■ PL5.1 Laser, CRU and Toner Dispense (page 9-32)
■ PL8.1 Print Engine Electrical (page 9-40)
Non-Xerox Toner Cartridge Troubleshooting Procedure
Step Actions and Questions Yes No
1
Check the Toner Cartridge installation.
Was a Xerox Toner Cartridge replaced?
Go to Step 2. Replace with a
Xerox Toner
Cartridge. If the
error persists, go
to Step 2.
2
Check the Toner Cartridge CRUM PWB
installation.
Is the Toner Cartridge CRUM PWB
installed correctly?
Go to Step 3. Correct the
installation.
3
Check the Toner Cartridge CRUM PWB
connection.
Are P127 and P/J419 connected?
Go to Step 4. Connect P127
and P/J419.
4
Check continuity between the Toner CRUM
PWB and Engine Logic Board.
1. Disconnect P127 and P/J419.
2. Check for continuity at the following:
P127-6 <=> P/J419-6
P127-5 <=> P/J419-7
P127-4 <=> P/J419-8
P127-3 <=> P/J419-9
P127-2 <=> P/J419-10
Are these conductive?
Go to Step 5. Repair the wiring.
