3-216 Phaser 5500 Printer Service Manual
11
Check the tray’s rollers.
Remove the tray.
Is the Feed, Retard or Nudger Roller
worn or contaminated?
Go to Step 12. Clean or replace
the affected roller.
12
Check paper jam position.
Open Door A.
Does the paper touch the Registration
Sensor?
Remove the paper
and go to Step 15.
Go to Step 13.
13
Check the Take Away Roller.
Open Door C.
Is the Take Away Roller worn or
contaminated?
Clean or replace
the Take Away
Roller.
Go to Step 14.
14
Check the Registration Roller.
Open Door A.
Is the Registration Roller worn or
contaminated?
Clean or replace
the rolls.
Go to Step 15.
15
Test the Registration Sensor.
1. Run the Service Diagnostics
Registration Sensor test.
2. Open Door A.
Does the sensor status change when
the actuator is moved?
Go to Step 19. Go to Step 16.
16
Check the Registration Sensor connection.
Are J104 and J403B connected?
Go to Step 17. Connect J104
and J403.
17
Check continuity between the Registration
Sensor and Engine Logic Board.
Is there continuity on each wire
between J104 <=> J403?
Go to Step 18. Repair the wiring.
18
Check for +5 V to the Registration Sensor.
Is there +5 V across J403-B13 (+) <=>
ground?
Replace the
Registration
Sensor
(
page 8-52).
Replace the
Engine Logic
Board
(
page 8-89).
19
Test the Registration Clutch.
Run the Service Diagnostics Registration
Clutch test.
Does the Registration Clutch operate?
Replace the
Engine Logic
Board
(
page 8-89).
Go to Step 20.
20
Check Registration Clutch connections.
Are P215 and P/J403 connected?
Go to Step 21. Connect P215
and P/J403.
21
Check continuity between the Registration
Clutch and Engine Logic Board.
Is there continuity on each wire
between P215 <=> P/J403?
Go to Step 22. Repair the wiring.
Paper Size Mismatch in Tray 4 or 5 Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
