Parts Lists 9-9
Parts List 2.1 Tray 1/2 and Feeder 1/2
No. Name/Description Part Number
1 STOPPER-TRAY 003E58700
2 SPACER TRAY G 014E44710
3 TRAY ASSY (PL 2.2, included with 99)
4 SWITCH ASSY P S (Paper Size Switch) 110K11680
5 BRACKET-SW
6 CHUTE ASSY FEEDER 054K24091
7 FEEDER ASSY (PL2.3.2.1) 059K26934
9 CHUTE FEED OUT (with 13, 14) 054K27550
10 LABEL, TRAY NO1 (included with 97)
11 LABEL, TRAY NO2 (included with 97)
12 LABEL INST,M/N
13 CHUTE FEED OUT
14 PAD ASSY LH LOW
15 COVER SENSOR
97 KIT LABEL (with 10, 11, PL20.2.2, PL20.2.3) 604K23370
98 TRAY, ENVELOPE (as option, not shown) 604K24320
99 500 TRAY 109R00733
