Parts Lists 9-23
Parts List 4.1 Transportation and Registration L/H Lower
No. Name/Description Part Number
1 BRKT ASSY TA (with 2,3) (Take Away Bracket) 015K61010
2 BRACKET ASSY IDLER
3 SWITCH-I/L, CAB (Door B Interlock Switch) 110E11580
4 RIVET 029E31600
5 CHUTE-LOWER
6 BEARING TA 013E26990
7 GEAR - 18T 007E79270
8 ROLLER ASSY-TA (Take Away Roller) 059K26840
9 BEARING SLEEVE 413W77559
10 COVER ASSY LH LOW C (with 11~22) (Door B) 802K58280
11 CHUTE LH LOW C
12 HANDLE LH LOW
13 SPRING-COMP LH LOW
14 COVER LH LOW C
15 PLATE-EARTH
16 BRKT ASSY LH LOW C (with 17~22)
17 BRKT LH LOW
18 ROLLER-TA PINCH
19 BEARING-OUT
20 BEARING-IN
21 SPRING LH LOW
22 SPRING
To Next Page
