Parts Lists 9-25
Parts List 4.2 L/H Upper Assembly
No. Name/Description Part Number
1 HSG ASSY-BTR -- Periodic replacement part (per 300k prints)
(Transfer Roller)
802K56094
2 COVER ASSY-CONTACT 802K49240
3 LINK ASSY-SHUTTER 012K94341
4 SWITCH (Door A Interlock Switch) 110E94770
5 BRACKET ILSW
6 STUD 826E08440
7 CHUTE ASSY LH (PL4.3.1)
8 COVER ASSY-LH (PL4.4.1)
