Parts Lists 9-29
Parts List 4.4 L/H Cover Assembly
No. Name/Description Part Number
1 COVER ASSY-L/H (with 2~10) (Door A) 802K58260
2 HANDLE L/H 003E59832
3 ROD CRU SHUTTER 024E03250
4 CHUTE LHCOV
5 -
6 CHUTE ASSY-DUP 054K24060
7 FRAME ASSY LH
8 COVER-LH
9 SPRING COMP LH 809E42460
10 SUPPORT - LH COVER (Door A Stopper) 849E13981
