Parts Lists 9-31
Parts List 4.5 Registration
No. Name/Description Part Number
1 TRANS ASSY REGI (with 2~8) (Registration Transport Assembly) 059K26820
2 CLUTCH ASSY REGI H (Registration Clutch) 121K32660
3 CHUTE-REGI
4 ROLLER REGI IDLER
5 ROLLER ASSY REGI
6 BEARING REGI E
7 SNR ASSY REGI (Registration Sensor) 130K64270
8 PLATE-EARTH F G
9 CHUTE-TA 054E23910
10 CHUTE ASSY-R 054K23940
11 BEARING 013E26090
12 SHAFT TA
13 GEAR-19T 007E79320
14 CLUTCH ASSY-TA (Take Away Clutch) 121K31640
15 BRACKET-TA
16 BEARING 013E26060
17 CHUTE-TA (with 9, 18, 19) (Take Away Chute)
18 SENSOR (Feed Out Sensor #3) 930W00211
19 HARNESS
20 PUSH TIE
To Next Page
