Parts Lists 9-33
Parts List 5.1 Laser, CRU and Toner Dispense
No. Name/Description Part Number
1 BLOCK STOPPER CRU ] 014E44733
2 SCREW
3 PLATE-SW-INTLK 815E05030
4 SWITCH ASSY XERO INTLK (Drum Cartridge Detect Switch) 110K11810
5 SENSOR HUM & TE (Environmental Sensor Temp/Humidity PWB) 130K87980
6 GUIDE ASSY SUB 032K96910
7 HSG ASSY LASER C 802K73190
8 PWBA CRUM CP1 (Drum Cartridge/Toner Cartridge CRUM) 160K95830
9 HARN ASSY FRONT A
10 GUIDE ASSY CTG30 SUB (Toner Dispense Assembly) 032K96951
11 MOTOR ASSY-DISP 30K (Toner Dispense Motor) 127K38040
12 DUCT FUSER
13 FAN FUSER 127K37880
14 ROS ASSY-12 (Laser Assembly) 062K13614
15 CRU DRUM CARTRIDGE 113R00670
16 TONER CARTRIDGE 113R00668
17 DUCT INTAKE
18 CRU FAN (Drum Cartridge Fan 927W00112
98 DRUM CARTRIDGE CONN (Drum Cartridge Connector) 114E14880
