Parts Lists 9-35
Parts List 6.1 Fuser and Exit 1
No. Name/Description Part Number
1 SHAFT-ACTUATOR
2 --
3 ACTUATOR-EXIT (included with 99)
4 SENSOR PHOTO (Fuser Exit Sensor included with 99)
5 SPRING-ACTUATOR (included with 99)
6 BRKT-SENSOR, EXIT (included with 99)
7 FUSER ASSY 120V --- Periodic replacement part (per 300k prints) 126K18300
7 FUSER ASSY 220V --- Periodic replacement part (per 300k prints) 126K18310
8 TRANS ASSY EXIT (PL6.2)
99 KIT EXIT SENSOR (with 3~6) (Fuser Exit Sensor Kit) 015K60900
