Parts Lists 9-37
Parts List 6.2 Exit 1
No. Name/Description Part Number
1 TRANS ASSY EXIT (with 2~21, 34, 35) (Exit Transport Assembly) 059K31550
2 HARN ASSY EXIT 1 C
3 MOTOR ASSY-OFFSET (Offset Motor) 127K37951
4 PLATE-EARTH MOTOR
5 SENSOR-PHOTO IN (Offset Home Position or Full Stack Sensor) 930W00113
6 BEARING
7 GEAR-19T
8 CAP
9 GEAR-EXIT
10 BEARING ROLL
11 CHUTE-OCT1
12 SPRING-PINCH EXIT
13 RLR-PINCH EXIT
14 ROLL ASSTY OCT
15 CHUTE-LOW
16 BRACKET SENSOR
17 GEAR-OFFSET
18 SPRING-GATE 809E42370
19
GATE-EXIT 1 (Exit Gate)
050E19802
20 BEARING
21 PLATE-EARTH
22 COVER-TOP, EXIT 1 802E55151
23 BRKT-EXIT 2
24 ELIMINATOR EXIT
25 GUIDE-TRAY EXIT 1
26 ACTUATOR FULLSTACK 120E22171
27 ACTUATOR 120E24670
28 WEIGHT-ASSY PAPER 036K91600
29 PAD EXIT A
30 PAD EXIT B
31 PAD EXIT C
32 LABEL EXIT 1 XC
33 LABEL CAUTION XC
34 SEAL A
35 SEAL B
To Next Page
