Parts Lists 9-39
Parts List 7.1 Drive
No. Name/Description Part Number
1 COLLAR
2 GEAR 21/21T MSI
3 GEAR 18T MSI
4 GEAR 28T TA
5 BELT-SYNCHRONOUS BAN (Main Drive Belt) 423W13155
6 DRIVE ASSY 242 (with 7, 8number) (Motor Assembly) 007K88596
7 MOTOR ASSY 242
8 PULLEY 25T 020E36600
9 FLANGE EXIT 005E17860
99 KIT, GEAR (with 1, 2, 3, 4) 604K23270
