Parts Lists 9-41
Parts List 8.1 Electrical
No. Name/Description Part Number
1 PSHV-Y2 High-Voltage Power Supply (HVPS) 105E11420
2 SWITCH-POWER 110E11320
3 BRACKET-SW CPR
4 PWB A EXIT (Exit PWB) 160K94216
5 PWBA MCU F 110V/220V (Engine Logic Board) 960K06080
6 PWB SUPP EDGE
7 BRACKET MCU
8 POWER UNIT-C1(100/127) Low-Voltage Power Supply (LVPS) 105E11390
POWER UNIT C1H(200/240) Low-Voltage Power Supply (LVPS) 115E11400
9 CHOKE COIL (220/240) 104E94080
10 CHAS ASSY AC XC (with 11~16) (AC Accessory Panel)
11 SCREW
12 BRACKET-CONN AC
13 BREAKER GFI INL (GFI Breaker) 908W01201
14 HARNESS ASSY F/G,E
15 HARN ASSY AC US EU
16 OUTLET MN
17
18
19
20 COVER ASSY ESS (I/P Board Cover) 802K73070
21 PANEL ASSY CONN HCF
22 BRKT GUIDE PRX
23 CHASSIS ASSY ESS PRX
24 BRKT-EXIT LOW
25 IMAGE PROCESSOR BOARD (with NVRAM) 650-4341-00
26 PLATE ASSY LVPS
27 PKG POWER CORD (110V) 673K44480
28 PKG POWER CORD (220V) 673K55640
29 NVRAM DEVICE (I/P Board NVRAM) 163-1459-00
30 BASE CONFIG CARD (Networking disabled) 163-1518-00
31 NETWORK CONFIG CARD (Networking enabled) 163-1519-00
32 HARD DRIVE 650-4343-00
33 FLASH RAM (Optional flash memory) 671-5338-0A
34 128 MB DIMM 156-4860-00
35 256 MB DIMM 156-4663-00
