A-8 Phaser 5500 Printer Service Manual
Finisher Sensor/Switch
Tests
Test the sensors and switches
for the Finisher/Stacker, punch
and stapler.
Front Tamper Home Sensor
Rear Tamper Home Sensor
Staple Move Position Sensor
Staple Head Low Staple Sensor
Staple Head Self Priming Sensor
Staple Head Home Sensor
Lower Tray No Paper Sensor
Lower Tray Upper Limit Sensor
Stacker Encoder Sensor
Stack Height Sensor 1
Stack Height Sensor 2
Solenoid/Clutch Tests
Print Enegine Solenoid/
Clutch Test:
Test the functionality of
Solenoids and Clutches.
Registration Clutch
Tray 1/MPT Feed Solenoid
Take Away Clutch
Exit 2 Solenoid/Clutch Test Exit 2 Gate Solenoid
Tray 4 & 5 Clutch Test Take Away Clutch
Tray 6 Solenoid Tests Tray 6 Nudger Solenoid - High Power
Tray 6 Nudger Solenoid - Low Power
Finisher Solenoid/Clutch
Tests
Buffer Gate Solenoid (Path Out)
Buffer Gate Solenoid (Path In)
Transport Gate Solenoid (Upper Tray)
Transport Gate Solenoid (Lower Tray)
Sub Paddle Solenoid
Set Clamp Clutch
IP NVRAM Access:
This menu lets you reset
NVRAM locations.
PostScript NVRAM Reset
Factory NVRAM Reset
Engine Logic Board
Replacement
Saves/restores NVRAM
locations from Engine Logic
Board when replaced.
Save from Engine Board
Restore to Engine Board
Finisher Board Setup
Sets the Finisher/Stacker
board configuration.
Read Current Status
Set 3-Hole Punch & Staple (Finisher)
Set 2/4-Hole Punch & Staple (Finisher)
Set No Punch & No Staple (Stacker Only)
Exit Reboots Printer out of Diagnostics.
Service Diagnostics Tests (Continued)
