Use of diagnostic steps
GI-4
Use of diagnostic steps
Use of basic inspection
Ÿ Basic inspection to be carried out prior to the diagnostics。
Ÿ The diagnostic operation shall be implemented according to the order listed in the Table.
Ÿ Detailed operation of each basic inspection listed in the Table.
Ÿ Although the inspection and adjustment are carried out as per the operation steps listed in the Table，the
corresponding fault diagnostic items in the Table can be directly found and checked and repaired as per
the relative diagnostic procedures, if the fault reasons have been identified by the basic inspection.
Use of diagnostic index
Ÿ The fault diagnostics are listed in the diagnostic index to discover and solve the system faults.
Ÿ The fault diagnostics may be found in the details.
Sequence of
inspection
Contents of operation steps
Precautions to be taken in the
result of inspection
