General Precautions of EFI System Maintenance
F-119
S/N P-CODE UAES Description
EUIV EOBD
CLASS
Whether
SVS
lamp
lights
Whether
MIL lamp
lights
99 P0688 Improper Output Voltage of Main Relay 5 × ×
100 P0691
Control Circuit of Cooling Fan Relay Short to
Ground (Low Speed)
30 √ ×
101 P0692
Control Circuit of Cooling Fan Relay Short to
Power Supply (Low Speed)
30 √ ×
102 P0693
Control Circuit of Cooling Fan Relay Short to
Ground (High Speed)
30 √ ×
103
P0694
Control Circuit of Cooling Fan Relay Short to
Power Supply (High Speed)
30 √ ×
104 P0704 Improper Clutch Pedal Switch Signal 5 × ×
105
P1336
Torque Limit Function of Electronic Throttle
Security Monitoring
6 × ×
106
P1545
Deviation between Actual and Target Position
of Electronic Throttle Exceeding Limit Range
13 √ √
107
P1558
Too Large Resistance for Electronic Throttle
Opening
13 √ √
108
P1559
Self-learning Malfunction of Electronic
Throttle
6 × ×
109
P1564
System Voltage for Electronic Throttle
Self-learning Dissatisfied
6 × ×
110
P1565
Self-learning Malfunction of Electronic
Throttle Lower Limit Position Initiation
13 √ √
111
P1568
Too Large Resistance for Electronic Throttle
Return
13 √ √
112
P1579
Electronic Throttle Self-learning Condition
Dissatisfied
6 × ×
113
P1604
Self-learning Malfunction of Electronic
Throttle Gain Control
6 × ×
114 P1610 Secret Key and Security Code not Programmed 38 √ ×
115 P1611 Security Code Receiving Malfunction 38 √ ×
116 P1612 Challenge Request Failure 35 √ ×
117 P1613 IMMO Code Request Failure 35 √ ×
118 P1614 Transponder Verification Error 35 √ ×
119 P1651 SVS Lamp Drive Circuit Malfunction 5 × ×
120
P2088
Malfunction of air intake VVT short circuit to
ground
3 × √
121
P2089
Malfunction of air intake VVT short circuit to
power supply
3 × √
122
P2090
Malfunction of air exhaust VVT short circuit to
ground
3 × √
123 P2091
Malfunction of air exhaust VVT short circuit to
3 × √
