Procedure
Analyzer Initial Screen
2
Analyzer Basic Settings
Segment Selection
Use or to select the
segment for which to change the setting, and
press .
When you want to add a segment:
Press .
When you want to delete a segment:
Use or to select the segment
and press .
1
Setting the measurement level.
Setting the measurement range.
Setting the measurement speed.
Setting the average.
Setting the trigger delay.
Setting the DC bias.
3
Segment Setting
Select the segment setting.
(Example: When the setting is )
Setting the frequency.
(When the setting is , , or )
The setting for DC bias is common to all segments.
A different value cannot be set for each segment.
To Next Page
