5.7 Judging Measurement Results (Comparator Function)
214
When Editing Local Minimum Value
Use or to select the local minimum value
(MIN) you want to edit, and press .
Press to return to the measurement screen.
Set the left, right, upper, and lower limit values in the same
way.
When the judgment result is NG
15
The comparator range, overall judgment indication, and details of the judgment result are
displayed in the graph.
When Judgment Result is NG
