5.7 Judging Measurement Results (Comparator Function)

215

5

Chapter 5 ANALYZER Function

Measurement Result List

Judgment Result Details Display

Display details of the judgment result.

See "Viewing Details of the Judgment Result"

(p. 216)

When you want to display details of the judg-

ment result

Press .

Press .

When the judgment result is IN

Analyzer Initial Screen
