100 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
Table 12 :DISPlay Commands Summary
Command Query Options and Query Returns
:DISPlay:ANNotation<n
> {{0 | OFF} | {1 |
ON}} (see page 362)
:DISPlay:ANNotation<n
>? (see page 362)
{0 | 1}
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:ANNotation<n
>:BACKground <mode>
(see page 363)
:DISPlay:ANNotation<n
>:BACKground? (see
page 363)
<mode> ::= {OPAQue | INVerted |
TRANsparent}
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:ANNotation<n
>:COLor <color> (see
page 364)
:DISPlay:ANNotation<n
>:COLor? (see
page 364)
<color> ::= {CH1 | CH2 | CH3 |
CH4 | DIG | MATH | REF | MARKer |
WHITe | RED}
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:ANNotation<n
>:TEXT <string> (see
page 365)
:DISPlay:ANNotation<n
>:TEXT? (see page 365)
<string> ::= quoted ASCII string
(up to 254 characters)
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:ANNotation<n
>:X1Position <value>
(see page 366)
:DISPlay:ANNotation<n
>:X1Position? (see
page 366)
<value> ::= an integer from 0 to
(800 - width of annotation) in
NR1 format.
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:ANNotation<n
>:Y1Position <value>
(see page 367)
:DISPlay:ANNotation<n
>:Y1Position? (see
page 367)
<value> ::= an integer from 0 to
(480 - height of annotation) in
NR1 format.
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:CLEar (see
page 368)
n/a n/a
n/a :DISPlay:DATA?
[<format>][,][<palett
e>] (see page 369)
<format> ::= {BMP | BMP8bit |
PNG}
<palette> ::= {COLor | GRAYscale}
<display data> ::= data in IEEE
488.2 # format
:DISPlay:INTensity:WA
Veform <value> (see
page 370)
:DISPlay:INTensity:WA
Veform? (see page 370)
<value> ::= an integer from 0 to
100 in NR1 format.
:DISPlay:LABel {{0 |
OFF} | {1 | ON}} (see
page 371)
:DISPlay:LABel? (see
page 371)
{0 | 1}
