29 :SBUS<n> Commands
:SBUS<n>:FLEXray Commands
NOTE
These commands are only valid when the FLEXray triggering and serial decode option (Option
FLEX) has been licensed.
Table 116 :SBUS<n>:FLEXray Commands Summary
Command Query Options and Query Returns
:SBUS<n>:FLEXray:AUTo
setup (see page 826)
n/a n/a
:SBUS<n>:FLEXray:BAUD
rate <baudrate> (see
page 827)
:SBUS<n>:FLEXray:BAUD
rate? (see page 827)
<baudrate> ::= {2500000 | 5000000
| 10000000}
:SBUS<n>:FLEXray:CHAN
nel <channel> (see
page 828)
:SBUS<n>:FLEXray:CHAN
nel? (see page 828)
<channel> ::= {A | B}
n/a :SBUS<n>:FLEXray:COUN
t:NULL? (see page 829)
<frame_count> ::= integer in NR1
format
:SBUS<n>:FLEXray:COUN
t:RESet (see page 830)
n/a n/a
n/a :SBUS<n>:FLEXray:COUN
t:SYNC? (see page 831)
<frame_count> ::= integer in NR1
format
n/a :SBUS<n>:FLEXray:COUN
t:TOTal? (see
page 832)
<frame_count> ::= integer in NR1
format
:SBUS<n>:FLEXray:SOUR
ce <source> (see
page 833)
:SBUS<n>:FLEXray:SOUR
ce? (see page 833)
<source> ::= {CHANnel<n>}
<n> ::= 1-2 or 1-4 in NR1 format
:SBUS<n>:FLEXray:TRIG
ger <condition> (see
page 834)
:SBUS<n>:FLEXray:TRIG
ger? (see page 834)
<condition> ::= {FRAMe | ERRor |
EVENt}
:SBUS<n>:FLEXray:TRIG
ger:ERRor:TYPE
<error_type> (see
page 835)
:SBUS<n>:FLEXray:TRIG
ger:ERRor:TYPE? (see
page 835)
<error_type> ::= {ALL | HCRC |
FCRC}
:SBUS<n>:FLEXray:TRIG
ger:EVENt:AUToset
(see page 836)
n/a n/a
:SBUS<n>:FLEXray:TRIG
ger:EVENt:BSS:ID
<frame_id> (see
page 837)
:SBUS<n>:FLEXray:TRIG
ger:EVENt:BSS:ID?
(see page 837)
<frame_id> ::= {ALL | <frame #>}
<frame #> ::= integer from 1-2047
