:SEARch Commands 30
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 1009
:SEARch:PEAK Commands
Table 128 :SEARch:PEAK Commands Summary
Command Query Options and Query Returns
:SEARch:PEAK:EXCursio
n <delta_level> (see
page 1010)
:SEARch:PEAK:EXCursio
n? (see page 1010)
<delta_level> ::= required
change in level to be recognized
as a peak, in NR3 format.
:SEARch:PEAK:NPEaks
<number> (see
page 1011)
:SEARch:PEAK:NPEaks?
(see page 1011)
<number> ::= max number of peaks
to find, 1-11 in NR1 format.
:SEARch:PEAK:SOURce
<source> (see
page 1012)
:SEARch:PEAK:SOURce?
(see page 1012)
<source> ::= {FUNCtion<m> |
MATH<m>} (must be an FFT
waveform)
<m> ::= 1 to 4 in NR1 format
:SEARch:PEAK:THReshol
d <level> (see
page 1013)
:SEARch:PEAK:THReshol
d? (see page 1013)
<level> ::= necessary level to be
considered a peak, in NR3 format.
