:SBUS<n> Commands 29
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 973
:SBUS<n>:USB:SOURce:DPLus
(see page 1428)
Command Syntax
:SBUS<n>:USB:SOURce:DPLus <source>
<source> ::= {CHANnel<n>} for DSO models
<source> ::= {CHANnel<n> | DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels) in NR1 format
<d> ::= 0 to (# digital channels - 1) in NR1 format
The :SBUS<n>:USB:SOURce:DPLus command specifies which signal is used as the
USB D+ source for the selected bus.
The D+ source is only used for Low and Full Speed USB.
Query Syntax
:SBUS<n>:USB:SOURce:DPLus?
The :SBUS<n>:USB:SOURce:DPLus? query returns the specified D+ source.
Return Format
<source><NL>
<source> ::= {CHAN<n> | DIG<d>}
See Also • ":SBUS<n>:USB:SOURce:DMINus" on page 972
• ":SBUS<n>:USB:SPEed" on page 975
