974 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
29 :SBUS<n> Commands
:SBUS<n>:USB:SOURce:DIFFerential
(see page 1428)
Command Syntax
:SBUS<n>:USB:SOURce:DIFFerential <source>
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels) in NR1 format
The :SBUS<n>:USB:SOURce:DIFFerential command specifies which signal is used
as the differential source for the selected bus.
Differential sources are only used for High Speed USB.
Query Syntax
:SBUS<n>:USB:SOURce:DIFFerential?
The :SBUS<n>:USB:SOURce:DIFFerential? query returns the specified differential
source.
Return Format
<source><NL>
<source> ::= {CHAN<n>}
See Also • ":SBUS<n>:USB:SPEed" on page 975
