:WAVeform Commands 34
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 1241
:WAVeform:BYTeorder
(see page 1428)
Command Syntax
:WAVeform:BYTeorder <value>
<value> ::= {LSBFirst | MSBFirst}
The :WAVeform:BYTeorder command sets the output sequence of the WORD data.
The parameter MSBFirst sets the most significant byte to be transmitted first. The
parameter LSBFirst sets the least significant byte to be transmitted first. This
command affects the transmitting sequence only when :WAVeform:FORMat
WORD is selected. The default setting is LSBFirst.
Query Syntax
:WAVeform:BYTeorder?
The :WAVeform:BYTeorder query returns the current output sequence.
Return Format
<value><NL>
<value> ::= {LSBF | MSBF}
See Also • "Introduction to :WAVeform Commands" on page 1235
• ":WAVeform:DATA" on page 1243
• ":WAVeform:FORMat" on page 1245
• ":WAVeform:PREamble" on page 1250
Example Code • "Example Code" on page 1256
• "Example Code" on page 1251
