1184 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
33 :TRIGger Commands
:TRIGger:NFC:TEVent
(see page 1428)
Command Syntax
:TRIGger:NFC:TEVent <trigger_event>
<trigger_event> ::= {ATRigger | ASReq | AALLreq | AEITher | ASDDreq
| BSReq | BALLreq | BEITher | BATTrib | FSReq | FAReq | FPReamble}
The :TRIGger:NFC:TEVent command specifies the trigger event. Valid trigger event
settings depend on the signaling technology selected (by
:TRIGger:NFC:STANdard):
Query Syntax
:TRIGger:NFC:TEVent?
The :TRIGger:NFC:TEVent? query returns the specified trigger event.
Return Format
<trigger_event><NL>
<trigger_event> ::= {ATR | ASR | AALL | AEIT | ASDD | BSR | BALL
| BEIT | BATT | FSR | FAR | FPR}
See Also • ":TRIGger:NFC:AEVent" on page 1180
Signaling
Technology
Trigger Event Description
NFC-A ATRigger The arm event is specified by :TRIGger:NFC:AEVent, and the
trigger event is SDD_REQ.
ASReq SENS_REQ
AALLreq ALL_REQ
AEITher Either the SENS_REQ or ALL_REQ events will cause a trigger.
ASDDreq SDD_REQ
NFC-B ATRigger The arm event is specified by :TRIGger:NFC:AEVent, and the
trigger event is ATTRIB.
BSReq SENSB_REQ
BALLreq ALLB_REQ
BEITher Either the SENSB_REQ or ALLB_REQ events will cause a trigger.
BATTrib ATTRIB
NFC-F ATRigger The arm event is specified by :TRIGger:NFC:AEVent, and the
trigger event is ATR_REQ.
FSReq SENSF_REQ
FAReq ATR_REQ
FPReamble The preamble sequence that begins a data frame will cause a
trigger.
