:SBUS<n> Commands 29
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 823
:SBUS<n>:CXPI:TRIGger:PATTern:INFO:NM
(see page 1428)
Command Syntax
:SBUS<n>:CXPI:TRIGger:PATTern:INFO:NM <string>
<string> ::= "nn" where n ::= {0 | 1 | X}
For the trigger types that let you trigger on data, as well as frame ID and frame
information bits, the :SBUS<n>:CXPI:TRIGger:PATTern:INFO:NM command lets
you specify the Network Management (NM) value of the CXPI frame you wish to
trigger on. This is a two-bit binary value.
Query Syntax
:SBUS<n>:CXPI:TRIGger:PATTern:INFO:NM?
The :SBUS<n>:CXPI:TRIGger:PATTern:INFO:NM? query returns the specified NM
bits included in the trigger.
Return Format
<string><NL>
<string> ::= "nn" where n ::= {0 | 1 | X}
See Also • ":SBUS<n>:CXPI:TRIGger" on page 813
• ":SBUS<n>:CXPI:TRIGger:IDFilter" on page 815
• ":SBUS<n>:CXPI:TRIGger:PTYPe" on page 816
• ":SBUS<n>:CXPI:TRIGger:PATTern:DATA" on page 817
• ":SBUS<n>:CXPI:TRIGger:PATTern:DATA:LENGth" on page 818
• ":SBUS<n>:CXPI:TRIGger:PATTern:DATA:STARt" on page 819
• ":SBUS<n>:CXPI:TRIGger:PATTern:ID" on page 820
• ":SBUS<n>:CXPI:TRIGger:PATTern:INFO:CT" on page 821
• ":SBUS<n>:CXPI:TRIGger:PATTern:INFO:DLC" on page 822
