542 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
22 :MEASure Commands
:MEASure:VAVerage
(see page 1428)
Command Syntax
:MEASure:VAVerage [<interval>][,<source>]
<interval> ::= {CYCLe | DISPlay}
<source> ::= {CHANnel<n> | FUNCtion<m> | MATH<m> | WMEMory<r>}
<n> ::= 1-2 or 1-4 (# of analog channels) in NR1 format
<m> ::= 1 to (# math functions) in NR1 format
<r> ::= 1 to (# ref waveforms) in NR1 format
The :MEASure:VAVerage command installs a screen measurement and starts an
average value measurement.
The <interval> option lets you specify the measurement interval: either an integral
number of cycles, or the full screen. If <interval> is not specified, DISPlay is
implied.
If the optional source parameter is specified, the current source is modified.
Query Syntax
:MEASure:VAVerage? [<interval>][,<source>]
The :MEASure:VAVerage? query returns the average value of an integral number of
periods of the signal.
Return Format
<value><NL>
<value> ::= calculated average value in NR3 format
See Also • "Introduction to :MEASure Commands" on page 488
• ":MEASure:SOURce" on page 529
