What's New 1
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 41
What's New in Version 4.07
New features in version 4.07 of the InfiniiVision 4000 X-Series oscilloscope
software are:
• Remote commands for remote command logging.
• Near Field Communication (NFC) trigger mode.
More detailed descriptions of the new and changed commands appear below.
New Commands
Command Description
:FUNCtion<m>[:FFT]:GATE (see
page 405)
Specifies whether the FFT is performed on the Main time base
window or the Zoom window when the zoomed time base is
displayed.
:MARKer:X1:DISPlay (see
page 456)
Specifies whether the X1 cursor is displayed.
:MARKer:X2:DISPlay (see
page 459)
Specifies whether the X2 cursor is displayed.
:MARKer:Y1:DISPlay (see
page 465)
Specifies whether the Y1 cursor is displayed.
:MARKer:Y2:DISPlay (see
page 467)
Specifies whether the Y2 cursor is displayed.
:SYSTem:RLOGger (see
page 1113)
Enables or disables remote command logging, optionally
specifying the log file name and write mode.
:SYSTem:RLOGger:DESTination
(see page 1114)
Specifies whether remote commands are logged to a text file (on a
connected USB storage device), logged to the screen, or both.
:SYSTem:RLOGger:DISPlay (see
page 1115)
Enables or disables the screen display of logged remote
commands and their return values (if applicable).
:SYSTem:RLOGger:FNAMe (see
page 1116)
Specifies the remote command log file name.
:SYSTem:RLOGger:STATe (see
page 1117)
Enables or disables remote command logging.
:SYSTem:RLOGger:TRANsparen
t (see page 1118)
Specifies whether the screen display background for remote
command logging is transparent or solid.
:SYSTem:RLOGger:WMODe
(see page 1119)
Specifies the remote command logging write mode (either CREate
or APPend).
:TRIGger:NFC Commands (see
page 1179)
Commands for setting up the Near Field Communication (NFC)
trigger mode.
