98 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:COMPliance:USB:TEST:
CONNection
<connection> (see
page 334)
:COMPliance:USB:TEST:
CONNection? (see
page 334)
<connection> ::= {SINGleended |
DIFFerential}
:COMPliance:USB:TEST:
TYPE <type> (see
page 335)
:COMPliance:USB:TEST:
TYPE? (see page 335)
<type> ::= {NEARend | FARend}
Table 8 :COMPliance Commands Summary (continued)
Command Query Options and Query Returns
Table 9 :COUNter Commands Summary
Command Query Options and Query Returns
n/a :COUNter:CURRent?
(see page 338)
<value> ::= current counter value
in NR3 format
:COUNter:ENABle {{0 |
OFF} | {1 | ON}} (see
page 339)
:COUNter:ENABle? (see
page 339)
{0 | 1}
:COUNter:MODE <mode>
(see page 340)
:COUNter:MODE (see
page 340)
<mode> ::= {FREQuency | PERiod}
:COUNter:NDIGits
<value> (see page 341)
:COUNter:NDIGits (see
page 341)
<value> ::= 5 normally, 8 with
10 MHz reference signal, in NR1
format
:COUNter:SOURce
<source> (see
page 342)
:COUNter:SOURce? (see
page 342)
<source> ::= {CHANnel<n> |
TQEVent}
<n> ::= 1 to (# analog channels)
in NR1 format
Table 10 :DEMO Commands Summary
Command Query Options and Query Returns
:DEMO:FUNCtion
<signal> (see
page 344)
:DEMO:FUNCtion? (see
page 347)
<signal> ::= {SINusoid | NOISy |
PHASe | RINGing | SINGle | AM |
CLK | GLITch | BURSt | MSO | RUNT
| TRANsition | RFBurst | SHOLd |
LFSine | FMBurst | ETE | CAN |
LIN | UART | I2C | SPI | I2S |
CANLin | ARINc | FLEXray | MIL |
MIL2 | USB | NMONotonic}
