Obsolete and Discontinued Commands 37
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 1377
:SAVE:IMAGe:AREA
(see page 1428)
Query Syntax
:SAVE:IMAGe:AREA?
The :SAVE:IMAGe:AREA? query returns the selected image area.
When saving images, this query returns SCR (screen). When saving setups or
waveform data, this query returns GRAT (graticule) even though graticule images
are not saved.
Return Format
<area><NL>
<area> ::= {GRAT | SCR}
See Also • "Introduction to :SAVE Commands" on page 725
• ":SAVE:IMAGe[:STARt]" on page 730
• ":SAVE:IMAGe:FACTors" on page 731
• ":SAVE:IMAGe:FORMat" on page 732
• ":SAVE:IMAGe:INKSaver" on page 733
• ":SAVE:IMAGe:PALette" on page 734
