:MEASure:PEDGes
(see page 1428)
Command Syntax
:MEASure:PEDGes [<source>]
<source> ::= {CHANnel<n> | FUNCtion<m> | MATH<m> | WMEMory<r>}
<n> ::= 1 to (# analog channels) in NR1 format
<m> ::= 1 to (# math functions) in NR1 format
<r> ::= 1 to (# ref waveforms) in NR1 format
The :MEASure:PEDGes command installs a rising edge count measurement on
screen. If the optional source parameter is not specified, the current source is
measured.
Query Syntax
:MEASure:PEDGes? [<source>]
The :MEASure:NEDGes? query measures and returns the on-screen rising edge
count.
Return Format
<value><NL>
<value> ::= the rising edge count in NR3 format
See Also • "Introduction to :MEASure Commands" on page 488
• ":MEASure:SOURce" on page 529
NOTE
This command is not available if the source is FFT (Fast Fourier Transform).
