318 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
10 :CHANnel<n> Commands
:CHANnel<n>:PROBe:ZOOM
(see page 1428)
Command Syntax
:CHANnel<n>:PROBe:ZOOM {{0 | OFF} | {1 | ON}}
<n> ::= 1 to (# analog channels) in NR1 format
When the N2820A high-sensitivity current probe is used with both the Primary and
Secondary cables, the :CHANnel<n>:PROBe:ZOOM command specifies whether
this cable will have the Zoom In waveform (ON) or the Zoom Out waveform (OFF).
The other cable will have the opposite waveform.
Query Syntax
:CHANnel<n>:PROBe:ZOOM?
The :CHANnel<n>:PROBe:ZOOM? query returns the zoom setting.
Return Format
<setting><NL>
<setting> ::= {0 | 1}
See Also • ":CHANnel<n>:PROBe:RSENse" on page 315
• ":MEASure:DUAL:CHARge" on page 502
• ":MEASure:DUAL:VAMPlitude" on page 503
• ":MEASure:DUAL:VAVerage" on page 504
• ":MEASure:DUAL:VBASe" on page 505
• ":MEASure:DUAL:VPP" on page 506
• ":MEASure:DUAL:VRMS" on page 507
