Keysight Technologies InfiniiVision MSO-X 4022A

:SEARch Commands 30
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 1039
:SEARch:SERial:CAN:SYMBolic:VALue
(see page 1428)
Command Syntax
:SEARch:SERial:CAN:SYMBolic:VALue <data>
<data> ::= value in NR3 format
The :SEARch:SERial:CAN:SYMBolic:VALue command specifies the signal value to
search for when CAN symbolic data has been loaded (recalled) into the
oscilloscope and the CAN serial search mode is set to MSIGnal.
Query Syntax
:SEARch:SERial:CAN:SYMBolic:VALue?
The :SEARch:SERial:CAN:SYMBolic:VALue? query returns the specified signal
value.
Return Format
<data><NL>
<data> ::= value in NR3 format
See Also • ":RECall:DBC[:STARt]" on page 716
• ":SEARch:SERial:CAN:MODE" on page 1031
• ":SEARch:SERial:CAN:SYMBolic:MESSage" on page 1037
• ":SEARch:SERial:CAN:SYMBolic:SIGNal" on page 1038
NOTE
Encoded signal values are not supported in the remote interface (even though they can be
used in the front panel graphical interface).
