29 :SBUS<n> Commands
:SBUS<n>:FLEXray:TRIGger
(see page 1428)
Command Syntax
:SBUS<n>:FLEXray:TRIGger <condition>
<condition> ::= {FRAMe | ERRor | EVENt}
The :SBUS<n>:FLEXray:TRIGger:TRIGger command sets the FLEXray trigger on
condition:
• FRAMe — triggers on specified frames (without errors).
• ERRor — triggers on selected active error frames and unknown bus conditions.
• EVENt — triggers on specified FlexRay event/symbol.
Query Syntax
:SBUS<n>:FLEXray:TRIGger?
The :SBUS<n>:FLEXray:TRIGger? query returns the current FLEXray trigger on
condition.
Return Format
<condition><NL>
<condition> ::= {FRAM | ERR | EVEN}
See Also • "Introduction to :TRIGger Commands" on page 1139
• ":TRIGger:MODE" on page 1148
• ":SBUS<n>:FLEXray:TRIGger:ERRor:TYPE" on page 835
• ":SBUS<n>:FLEXray:TRIGger:EVENt:AUToset" on page 836
• ":SBUS<n>:FLEXray:TRIGger:EVENt:BSS:ID" on page 837
• ":SBUS<n>:FLEXray:TRIGger:EVENt:TYPE" on page 838
• ":SBUS<n>:FLEXray:TRIGger:FRAMe:CCBase" on page 839
• ":SBUS<n>:FLEXray:TRIGger:FRAMe:CCRepetition" on page 840
• ":SBUS<n>:FLEXray:TRIGger:FRAMe:ID" on page 841
• ":SBUS<n>:FLEXray:TRIGger:FRAMe:TYPE" on page 842
