894 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
29 :SBUS<n> Commands
:SBUS<n>:M1553:TRIGger:PATTern:DATA
(see page 1428)
Command Syntax
:SBUS<n>:M1553:TRIGger:PATTern:DATA <string>
<string> ::= "nn...n" where n ::= {0 |1|X}
The :SBUS<n>:M1553:TRIGger:PATTern:DATA command sets the 11 bits to trigger
on if the trigger type has been set to RTA11 (RTA + 11 Bits) using the
:SBUS<n>:M1553:TRIGger:TYPE command.
Query Syntax
:SBUS<n>:M1553:TRIGger:PATTern:DATA?
The :SBUS<n>:M1553:TRIGger:PATTern:DATA? query returns the current 11-bit
setting.
Return Format
<string><NL>
<string> ::= "nn...n" where n ::= {0 |1|X}
See Also • "Introduction to :TRIGger Commands" on page 1139
• ":SBUS<n>:M1553:TRIGger:TYPE" on page 896
• ":SBUS<n>:M1553:TRIGger:RTA" on page 895
