29 :SBUS<n> Commands
:SBUS<n>:LIN Commands
NOTE
These commands are valid when the automotive CAN and LIN serial decode option (Option
AMS) has been licensed.
Table 119 :SBUS<n>:LIN Commands Summary
Command Query Options and Query Returns
:SBUS<n>:LIN:DISPlay
<type> (see page 874)
:SBUS<n>:LIN:DISPlay?
(see page 874)
<type> ::= {HEXadecimal |
SYMBolic}
:SBUS<n>:LIN:PARity
{{0 | OFF} | {1 |
ON}} (see page 875)
:SBUS<n>:LIN:PARity?
(see page 875)
{0 | 1}
:SBUS<n>:LIN:SAMPlepo
int <value> (see
page 876)
:SBUS<n>:LIN:SAMPlepo
int? (see page 876)
<value> ::= {60 | 62.5 | 68 | 70
| 75 | 80 | 87.5} in NR3 format
:SBUS<n>:LIN:SIGNal:B
AUDrate <baudrate>
(see page 877)
:SBUS<n>:LIN:SIGNal:B
AUDrate? (see
page 877)
<baudrate> ::= integer from 2400
to 625000 in 100 b/s increments
:SBUS<n>:LIN:SOURce
<source> (see
page 878)
:SBUS<n>:LIN:SOURce?
(see page 878)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:LIN:STANdard
<std> (see page 879)
:SBUS<n>:LIN:STANdard
? (see page 879)
<std> ::= {LIN13 | LIN13NLC |
LIN20}
:SBUS<n>:LIN:SYNCbrea
k <value> (see
page 880)
:SBUS<n>:LIN:SYNCbrea
k? (see page 880)
<value> ::= integer = {11 | 12 |
13}
:SBUS<n>:LIN:TRIGger
<condition> (see
page 881)
:SBUS<n>:LIN:TRIGger?
(see page 881)
<condition> ::= {SYNCbreak | ID |
DATA}
