30 :SEARch Commands
:SEARch:SERial:CAN Commands
Table 132 :SEARch:SERial:CAN Commands Summary
Command Query Options and Query Returns
:SEARch:SERial:CAN:MO
DE <value> (see
page 1031)
:SEARch:SERial:CAN:MO
DE? (see page 1031)
<value> ::= {IDData | DATA |
IDRemote | IDEither | ERRor |
ACKerror | FORMerror | STUFferror
| CRCerror | ALLerrors | OVERload
| MESSage | MSIGnal}
:SEARch:SERial:CAN:PA
TTern:DATA <string>
(see page 1033)
:SEARch:SERial:CAN:PA
TTern:DATA? (see
page 1033)
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X} for
hexadecimal
:SEARch:SERial:CAN:PA
TTern:DATA:LENGth
<length> (see
page 1034)
:SEARch:SERial:CAN:PA
TTern:DATA:LENGth?
(see page 1034)
<length> ::= integer from 1 to 8
in NR1 format
:SEARch:SERial:CAN:PA
TTern:ID <string>
(see page 1035)
:SEARch:SERial:CAN:PA
TTern:ID? (see
page 1035)
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X} for
hexadecimal
:SEARch:SERial:CAN:PA
TTern:ID:MODE <value>
(see page 1036)
:SEARch:SERial:CAN:PA
TTern:ID:MODE? (see
page 1036)
<value> ::= {STANdard | EXTended}
:SEARch:SERial:CAN:SY
MBolic:MESSage <name>
(see page 1037)
:SEARch:SERial:CAN:SY
MBolic:MESSage? (see
page 1037)
<name> ::= quoted ASCII string
:SEARch:SERial:CAN:SY
MBolic:SIGNal <name>
(see page 1038)
:SEARch:SERial:CAN:SY
MBolic:SIGNal? (see
page 1038)
<name> ::= quoted ASCII string
:SEARch:SERial:CAN:SY
MBolic:VALue <data>
(see page 1039)
:SEARch:SERial:CAN:SY
MBolic:VALue? (see
page 1039)
<data> ::= value in NR3 format
