54 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
1 What's New
Command Differences From 3000 X-Series Oscilloscopes
The Keysight InfiniiVision 4000 X-Series oscilloscopes command set is most
closely related to the InfiniiVision 3000 X-Series oscilloscopes (and the
7000A/B Series, 6000 Series, and 54620/54640 Series oscilloscopes before them).
The main differences between the version 3.00 programming command set for the
InfiniiVision 4000 X-Series oscilloscopes and the 2.10 programming command set
for the InfiniiVision 3000 X-Series oscilloscopes are related to:
• Zone qualified trigger feature.
• USB 2.0 triggering and serial decode options (which replace the old
:TRIGger:USB commands).
• Two-channel built-in waveform generator (with Option WGN license) instead of
one channel.
• Support for modulation of the waveform generator output on WaveGen1.
• A couple new built-in demo signals (with Option EDU license that comes with
the N6455A Education Kit).
• Four reference waveforms (instead of two).
• Four math functions (instead of g(t) and f(t)).
• Touchscreen, sidebar, and display related command additions.
•Measure cursors mode.
• Support for controlling the optional DSOXDVM digital voltmeter analysis
feature.
• Power measurements application modifications.
More detailed descriptions of the new, changed, obsolete, and discontinued
commands appear below.
New Commands
Command Description
:ACQuire:RSIGnal (see
page 269)
Lets you select the 10 MHz reference signal mode.
:DISPlay:MENU (see
page 373)
Changes the front panel softkey menu.
:DISPlay:SIDebar (see
page 374)
Specifies the sidebar dialog to display on the screen.
:DVM Commands (see
page 377)
Commands for controlling the optional DSOXDVM digital
voltmeter analysis feature.
:FUNCtion<m>:AVERage:COUN
t (see page 394)
Specifies the count for the Averaged Value math function.
:MEASure:CPLoss (see
page 561)
Installs a power loss per cycle measurement on screen or returns
the measured value.
