What's New 1
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 51
What's New in Version 3.10
New features in version 3.10 of the InfiniiVision 4000 X-Series oscilloscope
software are:
• The DSOX4USBSQ USB 2.0 signal quality analysis application.
• Support for the N2820A high-sensitivity current probe.
• Saving Multi Channel Waveform data (*.h5) format files that can be opened by
the N8900A InfiniiView oscilloscope analysis software.
More detailed descriptions of the new and changed commands appear below.
New Commands
Command Description
:COMPliance Commands (see
page 325)
Commands for controlling the optional DSOX4USBSQ USB 2.0
signal quality analysis feature.
:MEASure:DUAL:CHARge (see
page 502)
These are special measurements available with the N2820A high
sensitivity current probe when both the Primary and Secondary
probe cables are used.
These measurements join the Zoom In waveform data below the
probe's clamp level with Zoom Out waveform data above the
probe's clamp level to create the waveform on which the
measurement is made.
:MEASure:DUAL:VAMPlitude
(see page 503)
:MEASure:DUAL:VAVerage (see
page 504)
:MEASure:DUAL:VBASe (see
page 505)
:MEASure:DUAL:VPP (see
page 506)
:MEASure:DUAL:VRMS (see
page 507)
:SAVE:COMPliance:USB[:STARt
] (see page 728)
Lets you save DSOX4USBSQ USB 2.0 signal quality test results.
:SAVE:MULTi[:STARt] (see
page 737)
Lets you save Multi Channel Waveform data (*.h5) format files
that can be opened by the N8900A InfiniiView oscilloscope
analysis software.
:TRIGger:LEVel:ASETup (see
page 1145)
Sets the trigger levels of all displayed analog channels to their
waveforms' 50% values.
