:MARKer Commands 21
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 471
:MARKer:YUNits:USE
(see page 1428)
Command Syntax
:MARKer:YUNits:USE
When PERCent is selected for :MARKer:YUNits, the :MARKer:YUNits:USE
command sets the current Y1 location as 0 percent and the current Y2 location as
100 percent.
Once the 0 and 100 percent locations are set, inputs to and outputs from the
:MARKer:Y1Position, :MARKer:Y2Position, and :MARKer:YDELta
commands/queries are relative to the set locations.
See Also • "Introduction to :MARKer Commands" on page 453
• ":MARKer:YUNits" on page 470
• ":MARKer:X1Y1source" on page 458
• ":MARKer:X2Y2source" on page 461
• ":MEASure:SOURce" on page 529
• ":MARKer:Y1Position" on page 466
• ":MARKer:Y2Position" on page 468
• ":MARKer:YDELta" on page 469
