Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 113
:MEASure:DUTYcycle
[<source>] (see
page 508)
:MEASure:DUTYcycle?
[<source>] (see
page 508)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | FUNCtion<m> |
MATH<m> | WMEMory<r>} for MSO
models
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= ratio of
positive pulse width to period in
NR3 format
:MEASure:FALLtime
[<source>] (see
page 509)
:MEASure:FALLtime?
[<source>] (see
page 509)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | FUNCtion<m> |
MATH<m> | WMEMory<r>} for MSO
models
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= time in
seconds between the lower and
upper thresholds in NR3 format
Table 19 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
