Keysight Technologies InfiniiVision MSO-X 4022A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 115
:MEASure:NPULses
[<source>] (see
page 513)
:MEASure:NPULses?
[<source>] (see
page 513)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= the falling
pulse count in NR3 format
:MEASure:NWIDth
[<source>] (see
page 514)
:MEASure:NWIDth?
[<source>] (see
page 514)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | FUNCtion<m> |
MATH<m> | WMEMory<r>} for MSO
models
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= negative
pulse width in seconds-NR3 format
:MEASure:OVERshoot
[<source>] (see
page 515)
:MEASure:OVERshoot?
[<source>] (see
page 515)
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
<return_value> ::= the percent of
the overshoot of the selected
waveform in NR3 format
Table 19 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
